Tripp Lite systems stop damaging surges and filter disruptive line noise, as well as correct power during a brownout. Their main
function, however, is to guarantee - through the use of battery backup - that constant power is supplied to equipment during blackout.
Select models include a wide range of additional features: 1- and 2- line phone/DSL surge protection; battery replacement doors;
expandable battery capabilities; rackmount designs; multiple communication ports; power management software and more.
EN | FR
208V 3-Phase UPS – Product Offering (30+ Models)
Key
Features
20K 30K 40K 60K 80K 100K 120K 140K 160kVA
S&M Biz - Server Rooms/Closets
Dedicated IT Space in small businesses and in
mixed-use buildings with ≤ 80 kW in IT load
S&M Data Centers
Light industrial and Large corporate networks with loads of
≤ 400 kW in IT load or 33 IT racks with 12kW/rack
SV
20/40/60/80/100/
120/140kVA
•
Modular/Scalable
•
Unity PF
•
98% ECO
Efficiency
•
NON-Parallelable
•
WebCard LX inc’d.
SUT 20/30K
SV 20K
SV 60K
SV 80K
SV 100KL
SV 120KL
SV 140KL
SUT 20/30/40/60kVA
•
Monolithic
•
Unity PF
•
98% ECO
Efficiency
•
Parallelable x 4
•
WebCardLX option
•
No Built-in Maint.
Bypass
SUT 40/60K
SV 40K
… EQUIPMENT RACKs
… CABLES
… COOLING
… KVMs
… PDUs
Small 20 – 60kVA
•
H 58.1” x W 23”.6 x D 43.3”
•
40kVa and N+1
•
1-3 Power Modules
•
1-3 Battery Modules
•
With or without battery
modules, “0B” models
Medium 20 – 80kVA
•
H 79.1” x W 23”.6 x D 43.3”
•
60kVA and N+1
•
1-4 Power Modules
•
1-4 Battery Modules
•
With or without battery
modules, “0B” models
Large 20 – 140kVA
•
H 79.1” x W 23”.6 x D 43.3”
•
140kVA and N+1
•
1-8 Power Modules
•
No Internal Battery
3 basic types of UPS Systems
Standby UPS System
Application: Protects PCs and workstations
Provide filtered, surge-protected, AC line power, switching to battery power during brownouts and blackouts.
Line Interactive UPS System
Application: Protect workstations, servers, datacenters and telecom/Internet working equipment
Provide filtered, surge-protected AC line power, switching to battery power only during blackouts. During brownouts,
these UPS systems automatically adjust voltage to normal levels, without relying on battery power.
On-Line UPS System
Application: Protect mission-critical servers and equipment
Provide continuously filtered, surge-protected and resynthesized AC line power with a pure sine wave. Constant on-line
operation provides zero transfer time to battery, protecting sensitive equipment against system crashes. They also
provide higher levels of line noise filtering and correction of harmonic distortion and frequency variation.
